Dwyer Key Area Indoor Pressure Monitor RPMC Series
Product Introduction：
Indoor pressure status indicator, same size as Magnehelic differential pressure gauge- Consultation Hotline：18615230752 Landline：0531-88975421
Product Details
Technical parameters
Application scenarios
Optional accessories
Contact Us
The PRMC series StabiliSENSE critical area indoor pressure monitors are designed for applications that require strict monitoring and interlocked alarms for micro-differential pressure. The RPMC series can be set to monitor positive or negative pressure, used in protected environments or clean production areas. The RPMC is fully featured, including pressure reading, safety level configuration, calibration, and alarm settings. It comes with a frosted stainless steel frame that’s easy to clean.
The RPMC series StabiliSENSE critical area indoor pressure monitors have LED status indicators that show green when within the user-set range and orange when out of range. Two independent SPDT switch outputs allow adjustment of the deadband and provide a 4-20mA output signal.
● Long-term stable pressure measurement
● Two single-pole double-throw switches can be used for both on-site alarms and control system alarms
● Automatic or manual alarm reset
● LED indicates alarm status on-site, allowing quick corrective action to prevent problems from spreading
● Records the maximum and minimum measured values
● Same installation size as Magnehelic differential pressure gauges, making on-site upgrades easy
● Password protection for the settings menu ensures it won’t be misused
